Display: 4 digits, 10 mm LCD, with blue backlight |
Parameters: Ra, Rz, Rq, Rt |
Measuring Range |
Ra, Rq: 0.005-16.00um/0.020-629.9uinch |
Rz,Rt: 0.020-160.0um/0.780-6299uinch |
Accuracy: ≤±10% |
Fluctuation of display value: Not more than 6% |
Sensor : |
Test Principle: Inductance type |
Radius of Probe Pin: 5um |
Material of Probe Pin: Diamond |
Dynamo-measurement of Probe: 4mN(0.4gf) |
Probe Angle: 90° |
Vertical Radius of Guiding Head: 48mm |
Maximum driving stroke: 17.5mm/0.7inch |
Cutoff length (l): 0.25mm / 0.8mm / 2.5mm optional |
Evaluation length: 5l |
Driving speed: |
sampling length = 0.25mm Vt=0.135mm/s |
sampling length = 0.8mm Vt=0.5mm/s |
sampling length = 2.5mm Vt=1mm/s |
returning Vt=1mm/s |
Profile digital filter |
Filtered Profile: RC |
Filtered Profile: PC-RC |
Filtered Profile: Gauss |
Non-Filtered Profile: D-P |
Resolution : .001μm if reading <10μm |
0.01μm if 10μm≤reading<100μm |
0.1μm if reading ≥100μm |
Evaluation length : 5 cut-off |
Power supply: 4x1.5 AAA(UM-4) battery |
Operating conditions: Temp. 0~40°C |
Humidity <80% |
Standard Accessories: |
Carrying case.................1pcs |
Main unit.....................1pcs |
Standard Sensor...............1pcs |
Standard Sample Plate.........1pcs |
Power Adapter.................1pcs |
Operation Manual..............1pcs |
Screwdriver...................1pcs |
Adjustable Leg................1pcs |
Sensor Protector..............1pcs |
Optional Accessories: |
1. Cable and Software for RS-232/USB |
2. Extension Rod |
3. Groove stylus |
4. Curvature Probe |
5. Measurement Stand |
6. Bluetooth interface |
