- measuring
range : -50℃ ~ 1300℃, -58℉ ~ 1999℉
- sensor
: k type thermocouple
- input
: single channel
- resolution
: -50℃ ~ 199.9℃...0.1℃
-50℉
~ 199.9℉...0.1℉
(others
1℃/1℉)
- accuracy
:
-50℃ ~ 0℃...±(0.5% rdg 1℃)
-50℉ ~ 0℉...±(0.5% rdg 2℉)
0℃ ~ 1000℃...±(0.3%
rdg 1℃)
0℉ ~ 1832℉. ..±(0.3%
rdg 2℉)
1000℃ ~ 1300℃..±(0.5% rdg 1℃)
1832℉ ~ 1999℉. ..±(0.5% rdg 2℉)
- temperature
coefficient :
less than 0.1 time the applicable accuracy
specification per ℃(℉)
- input
protection :
60v dc or 24 vrms ac maximum input voltage
on any combination of input connector
- sampling
rate : 2.5 times/sec
- operating
/ storage conditions : 0℃
~ 40℃<80% rh,
-10℃
~ 60℃<70% rh
- power
source : 6 pcs aaa size battery
- size
: 150mm(l) x 72mm(w) x 35mm(h)
- weight
: 235g
- accessories
: battery, instruction manual
-
*
optional temperature probes k(ca) type
thermocouple
model
|
testing
range
|
deion
|
tp-k01
bead
|
-50℃
- 200℃
-58℉
- 392℉
|
for
general condition,
especially
for complex place hard to reach
|
tp-k02
immersion
|
-50℃
- 1000℃
-58℉
- 1832℉
|
for
temperature measurement of liquid or gels
|
tp-k03
surface
|
-50℃
- 750℃
-58℉
- 1382℉
|
for
surface measurement
|
|
|
